Ležajna jedinica - S 617 KUVAL

Nije ocijenjeno Detalji ocjene

€136,04 / kom €112,43 bez PDV-a

Na skladištu (2 kom)

Dostava na: 15. 7. 2026 Mogućnosti dostave

Količinski popust

1 - 4 kom

€136,04 / kom

5 - 9 kom = popust 3 %

€131,96 / kom

10 - 24 kom = popust 6 %

€127,88 / kom

25 - 49 kom = popust 9 %

€123,80 / kom

50 i više kom = popust 12 %

€119,72 / kom

Uštedite €0

The Bearing Housing S 617 KUVAL is a robust, two-piece cast iron housing designed to securely support bearings in demanding industrial applications. It features a labyrinth seal to protect against contaminants and is suitable for both grease and oil lubrication.

Detaljne informacije

Što dobivate s nama

Pomoći ćemo vam pri odabiru vrste

Prema oznaci i dimenzijama

Plaćanje pouzećem bez nadoplate

Plaćate samo kada preuzmete

Čak i komponente koje je teško pronaći

Specijalni i stariji tipovi

Brza obrada zahtjeva

Pomoći ćemo vam pronaći rješenje

Prikaži sve povezane proizvode

Detaljan opis proizvoda

The Bearing Housing S 617 KUVAL is engineered to provide reliable support and protection for bearings in various industrial settings. Its design ensures durability and efficiency in operations.

Technical Specifications:

Material: Cast iron
Housing Type: Pillow block
Housing Configuration: Two-piece
Mounting Arrangement: Through shaft/Shaft end
Number of Bolt Holes for Fasteners: 2
Attachment Bolt Diameter: 22.225 mm
Center Height (Pillow Block): 114.3 mm
Center Distance Between Bolt Holes: 314.325 mm
Diameter of Bearing Seat: 180 mm
Housing Lubrication Feature/Possibility: Grease/Oil
Bearing Housing Seal Type: Labyrinth seal
Product Net Weight: 25.1 kg

This housing is designed to accommodate bearings with a 180 mm bore diameter, making it suitable for various shaft sizes. The labyrinth seal effectively prevents contaminants from entering the bearing area, thereby extending the service life of the bearings. The two-piece construction allows for easy installation and maintenance, reducing downtime in industrial operations.
