Componente - CPE18-M1H-* Festo

Descrição detalhada do produto

The Festo CPE18-M1H-* series comprises solenoid valves engineered for precise control in pneumatic systems. These valves are characterized by their compact design, high flow rates, and reliable operation.

Key Features:

• Valve Function: Available in 5/2-way and 5/3-way configurations, both monostable and bistable, to suit diverse control requirements.

• Actuation Type: Electrically actuated for precise and responsive control.

• Construction Width: Compact 18 mm width, facilitating integration into space-constrained installations.

• Flow Rate: Standard nominal flow rates up to 1,500 l/min, ensuring efficient operation in various applications.

• Operating Pressure: Suitable for operating pressures ranging from 0.25 MPa to 1 MPa (2.5 bar to 10 bar), accommodating a wide range of pneumatic systems.

• Pneumatic Connections: Options include G1/4 ports and QS-8 push-in fittings, providing flexibility in installation.

• Electrical Connection: Equipped with a plug socket conforming to IEC 60529, ensuring secure and standardized electrical connections.

• Degree of Protection: IP65 rating, offering protection against dust and water jets, suitable for demanding industrial environments.

• Operating Medium: Compatible with compressed air as per ISO 8573-1:2010 [7:4:4], with options for lubricated operation.

• Temperature Range: Operable within a medium temperature range of -5°C to 50°C and ambient temperature range of -5°C to 50°C.

• Materials: Housing made of die-cast aluminum; seals made of NBR; RoHS-compliant materials.

Technical Specifications:

• Coil Characteristics: 24 V DC: 1.5 W

• Permissible Voltage Fluctuations: -15% / +10%

• Switching Times:

  • Switching time off: 20 ms
  • Switching time on: 26 ms

• Duty Cycle: 100%

• Vibration Resistance: Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6

• Shock Resistance: Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27

• Corrosion Resistance Class: CRC 2 - Moderate corrosion stress

• LABS (PWIS) Conformity: VDMA24364-B1/B2-L

• Pilot Air Supply: Internal for certain models; external for others

• Pilot Exhaust Air Ports: M5 threads

• Pilot Air Ports: M5 threads

• Pneumatic Connections: G1/4 or QS-8, depending on model

These solenoid valves are ideal for applications requiring compact size, high flow rates, and reliable performance, such as automation systems, robotics, and industrial machinery.
