Palier - UCT 213 ZKL

Description détaillée du produit

The UCT 213 take-up bearing unit is engineered for material handling applications, providing reliable support and alignment for conveyor systems and similar machinery.

Technical Specifications:

• Housing Material: Cast iron
• Bearing Type: Radial insert ball bearing
• Locking Mechanism: Set screw in the inner ring
• Sealing Solution: Standard seals with additional flingers

Dimensions:

• d (Shaft Diameter): 65 mm
• d₁ (Housing Bore Diameter): 82.5 mm
• A (Housing Length): 126 mm
• B (Housing Height): 168.3 mm
• H (Mounting Height): 167 mm
• L (Center to Center Distance): 225 mm

Performance Data:

• Basic Dynamic Load Rating (C): 57.2 kN
• Basic Static Load Rating (C₀): 40 kN
• Fatigue Load Limit (Pu): 1.7 kN
• Limiting Speed: 2350 rpm with shaft tolerance h6

Mounting Information:

• Set Screw Size: M10x1
• Hexagonal Key Size for Set Screw: 5 mm
• Recommended Tightening Torque for Set Screw: 16.5 N·m

Included Components:

• Housing: T213
• Bearing Insert: UC213/H

Associated Products:

• End Cover: ECY 213

This unit is designed to provide robust support and alignment in material handling systems, ensuring efficient operation and longevity of the machinery.
