Descrição detalhada do produto
The UCT 213 take-up bearing unit is engineered for material handling applications, providing reliable support and alignment for conveyor systems and similar machinery.
Technical Specifications:
- Housing Material: Cast iron
- Bearing Type: Radial insert ball bearing
- Locking Mechanism: Set screw in the inner ring
- Sealing Solution: Standard seals with additional flingers
Dimensions:
- d (Shaft Diameter): 65 mm
- d₁ (Housing Bore Diameter): 82.5 mm
- A (Housing Length): 126 mm
- B (Housing Height): 168.3 mm
- H (Mounting Height): 167 mm
- L (Center to Center Distance): 225 mm
Performance Data:
- Basic Dynamic Load Rating (C): 57.2 kN
- Basic Static Load Rating (C₀): 40 kN
- Fatigue Load Limit (Pu): 1.7 kN
- Limiting Speed: 2350 rpm with shaft tolerance h6
Mounting Information:
- Set Screw Size: M10x1
- Hexagonal Key Size for Set Screw: 5 mm
- Recommended Tightening Torque for Set Screw: 16.5 N·m
Included Components:
- Housing: T213
- Bearing Insert: UC213/H
Associated Products:
- End Cover: ECY 213
This unit is designed to provide robust support and alignment in material handling systems, ensuring efficient operation and longevity of the machinery.
