Gedetailleerde beschrijving van het product
The Bearing Housing S 617 KUVAL is engineered to provide reliable support and protection for bearings in various industrial settings. Its design ensures durability and efficiency in operations.
Technical Specifications:
- Material: Cast iron
- Housing Type: Pillow block
- Housing Configuration: Two-piece
- Mounting Arrangement: Through shaft/Shaft end
- Number of Bolt Holes for Fasteners: 2
- Attachment Bolt Diameter: 22.225 mm
- Center Height (Pillow Block): 114.3 mm
- Center Distance Between Bolt Holes: 314.325 mm
- Diameter of Bearing Seat: 180 mm
- Housing Lubrication Feature/Possibility: Grease/Oil
- Bearing Housing Seal Type: Labyrinth seal
- Product Net Weight: 25.1 kg
This housing is designed to accommodate bearings with a 180 mm bore diameter, making it suitable for various shaft sizes. The labyrinth seal effectively prevents contaminants from entering the bearing area, thereby extending the service life of the bearings. The two-piece construction allows for easy installation and maintenance, reducing downtime in industrial operations.
