Adapter sleeve H 3144 ZKL



Related products

D = M200x3 mm,d = 180 mm,L = 118 mm

D = M200x3 mm,d = 180 mm,L = 125 mm

D= M180x3 mm,d = 160 mm,L = 146 mm

D = Tr220x4 mm,d = 190 mm,L = 134 mm

D = Tr280x4 mm,d = 240 mm,L = 128 mm

D= M75x2 mm,d = 60 mm,L = 61 mm

D = M130x2 mm,d = 115 mm,L = 93 mm

D= M60x2 mm,d = 50 mm,L = 54 mmThe FAG AHX 2311 withdrawal sleeve is a precision-engineered component designed to facilitate the mounting and dismounting of tapered bore bearings onto cylindrical...

D = M160x3 mm,d = 145 mm,L = 72 mm

D = M160x3 mm,d = 145 mm,L = 114 mm

D = M200x3 mm,d = 180 mm,L = 145 mm

D = Tr220x4 mm,d = 190 mm,L = 153 mm

D = M170x3 mm,d = 150 mm,L = 77 mm

D = M200x3 mm,d = 180 mm,L = 96 mm

D = M200x3 mm,d = 180 mm,L = 112 mm

D = Tr320x5 mm,d = 280 mm,L = 145 mm
Product detailed description
The SKF H 3144 adapter sleeve is a precision-engineered component that simplifies the assembly of bearings with a tapered bore onto cylindrical shafts. It is particularly useful for applications involving plain or stepped shafts, ensuring accurate alignment and secure positioning of the bearing.
Technical Specifications:
- Bore Diameter (d): 200 mm
- Outer Diameter (D): 280 mm
- Overall Length (L): 161 mm
- Thread Size (Tr): Tr220x4
- Taper: 1:12
- Lock Nut: HM44T
- Lock Washer: MB44
- Material: Steel
- Weight: Approximately 15.46 kg
Features:
- Easy Installation: Designed for straightforward mounting, reducing assembly time and complexity.
- Complete Set: Supplied with a lock nut and lock washer, ensuring all necessary components are included for secure installation.
- High Precision: Manufactured to exacting standards to provide accurate alignment and reliable performance.
- Durable Construction: Made from high-quality steel to withstand the demands of industrial applications.
This adapter sleeve is ideal for industries requiring robust bearing support, contributing to prolonged equipment lifespan and reduced maintenance needs. Its compatibility with various shaft sizes and ease of installation make it a versatile choice for many applications.
