Product sorting
List of products
85 × 150 × 38.5 mm
32217 A ZKL single-row tapered roller bearing for high combined radial and one-direction axial loads.
85x150x28 mm
Rolling bearing 6217 FLT for use in machinery and equipment.
85x130x34 mm
FAG bearing for industrial applications. When replacing a part, always verify the complete designation, dimensions, design and application requirements against the manufacturer documentation.
85x150x28 mm
SKF bearing for industrial applications. When replacing a part, always verify the complete designation, dimensions, design and application requirements against the manufacturer documentation.
85x150x30.5 mm
Bearing 30217 SKF is a precisely identified SKF product. Before ordering, compare the complete designation, dimensions and application requirements.
Greater radial internal clearance
85x180x41 mm
Rolling bearing 6317 CRE
Compare the complete designation, dimensions and application requirements before selecting.
Metal shields on both sides
Rubber seals on both sides
Injection moulded cage of glass fibre reinforced polyamide 66
85x180x41 mm
SKF bearing with the complete designation 6317 C3 SKF and increased radial internal clearance. Verify the complete designation, dimensions and internal-clearance requirement before ordering.
Large radial internal clearance
85x130x22 mm
Deep-groove ball bearing 6017 2RS ZVL with rubber seals on both sides for machinery applications.
Practical advice
How to choose the right bearing
The same dimensions do not necessarily mean the same function. When selecting a replacement, check the construction, cover and seal design, internal clearance, and the conditions in which the bearing will operate.
Determine the type and size
Copy the full type designation. If missing, measure the inner diameter d, outer diameter D and width B.
Check the design
Distinguish open bearing, metal shields, and rubber seals. Also check internal clearance, accuracy, cage, and lubricant.
Take operating conditions into account
Rotational speed, direction, and magnitude of mechanical load, temperature, humidity, dust, and the method of installation are decisive.
How to read the type designation 6204 2RS C3
Suffixes may vary between manufacturers. When replacing, compare technical parameters, not just similar type designation.
Open, 2Z, or 2RS?
When are matching dimensions not enough?
A dimensionally identical bearing may have different load capacity, maximum speed, precision, or internal clearance. Pay special attention to electric motors, high temperatures, vibrations, shocks, and dusty or humid environments.
- radial, axial, and combined loads
- normal or increased internal clearance C3/C4
- operating temperature and maximum speed
- design of shields and seals, lubricant, cage material, and precision
Frequently asked questions
Can I replace a bearing with another brand?
Usually yes, if the design type, dimensions, internal clearance, precision, cover and seal design, load capacity, and allowable speeds match. The basic number alone is not enough; the meaning of the suffixes may vary according to the manufacturer.
How do I determine the diameter of the inner bore from the model designation?
For many common metric bearings, the bore diameter code from 04 is multiplied by five: for example, 04 = 20 mm and 06 = 30 mm. Codes 00 to 03 and some special designs have different rules, so it is advisable to verify the dimension.
Is 2RS better, or 2Z?
Neither is universally better. 2RS usually protects better against dirt and moisture, while 2Z tends to have lower friction and allows higher speeds. The right choice depends on the application.
What to send if the type designation is unreadable?
A photo of both sides, dimensions d × D × B, machine type, and information about speed, load, temperature, humidity, or dustiness. The more operational data we know, the more safely a replacement can be recommended.
Not sure about the replacement?
Send the type designation, dimensions, or a photo of the original part. We will help verify the suitable version before ordering.
