Solenoid - Driven Metering Pump gamma/ X ProMinent
Related products
Product detailed description
The ProMinent gamma/ X is a state-of-the-art solenoid-driven diaphragm metering pump engineered for the precise dosing of liquid media across various industrial applications. It combines advanced technology with user-friendly features to ensure reliable and efficient operation.
Key Features:
-
Capacity and Pressure Range:
- Flow rate: 1 ml/h to 45 l/h
- Maximum discharge pressure: 25 bar
-
Integrated Pressure Measurement:
- Monitors back pressure to prevent system overloads
- Eliminates the need for a separate pressure sensor, enhancing operational safety
-
Solenoid Drive:
- Virtually wear-free, ensuring a long service life
- Overload-proof and economical
-
Continuous Micro-Metering:
- Suitable for dosing as low as 1 ml/h, thanks to the regulated solenoid drive
-
User-Friendly Interface:
- Simple adjustment of the metering rate directly in l/h
- Integrated pressure measurement and display for greater safety during commissioning and in the process
- Control range for metering rate: 1:40,000
-
Material Compatibility:
- Available in various material combinations to suit different chemical compatibilities
Technical Specifications:
-
Materials in Contact with the Medium:
- Dosing head: Polypropylene (PP), Clear Acrylic (NP), Polyvinylidene Fluoride (PVDF), PTFE with carbon (TTT), Stainless Steel (SS)
- Suction/pressure connector: PVDF, PVDF, PVDF, PTFE with carbon, Stainless Steel
- Ball seat: PTFE, PTFE, PTFE, Ceramic, Ceramic
- Seals: FPM (FKM), EPDM, PTFE, PTFE (FDA-compliant), FPM (FKM)
- Balls: Ceramic, Ceramic, Ceramic, Ceramic, Ceramic
-
Performance Data:
- Capacity range: 2.3 – 45 l/h
- Maximum back pressure: 25 bar
- Stroke rate: 200 strokes/min
- Suction lift: 6.0 m WC (with self-bleeding dosing head)
- Priming lift: 6.0 m WC
-
Electrical Data:
- Power supply: 100 V - 230 V, 50/60 Hz
- Degree of protection: IP 66 (NEMA 4X)
-
Dimensions:
- Gamma/ X 1602:
- ØA: 70 mm
- B: 71 mm
- C (with bleed valve): 106 mm
- D: 32 mm
- E: 198 mm
- Gamma/ X 1604:
- ØA: 70 mm
- B: 71 mm
- C (with bleed valve): 106 mm
- D: 32 mm
- E: 198 mm
- Gamma/ X 1602:
The gamma/ X is designed to meet the demands of various industries, providing precise and reliable dosing solutions. Its advanced features and robust construction make it a valuable asset for applications requiring accurate liquid metering.
