Needle roller bearing - HK0810 INA
Product detailed description
Needle roller bearing - HK0810 INA
HK 0810 INA drawn-cup needle roller bearing
HK 0810 INA is a drawn-cup needle roller bearing with open ends. Its thin-walled outer cup and design without a separate inner ring provide high radial load carrying capacity and stiffness with very low radial cross-sectional height.
Key features
- dimensions: 8 × 12 × 10 mm,
- drawn cup with open ends,
- high radial load capacity and stiffness in a compact cross-section,
- no separate inner ring,
- intended for radial load; axial location must be provided by the surrounding design.
Typical applications
Typical uses include gearboxes, power tools, automotive mechanisms, pumps and other compact assemblies where radial space is limited and the load is predominantly radial.
Mounting guidance
Press the cup into an accurately prepared housing bore with a suitable mounting mandrel, distributing force evenly and never striking the thin cup directly. A shaft used as the raceway must have the required hardness, accuracy, surface finish and diameter. Ensure suitable lubrication and cleanliness during assembly.
Replacement check: compare the designation HK 0810 INA, the dimensions 8 × 12 × 10 mm, the open ends and the shaft and housing requirements with the bearing being replaced.
Product rating
Be the first who will post an article to this item!
We can arrange delivery of almost any INA product, even if it is not currently listed in our catalogue.
Send us the designation, a photo of the nameplate, dimensions or a description of the application, and we will check availability.
INA – product identification and supply
The INA designation may appear on different technical products and spare parts. To identify the exact item reliably, we therefore work from the complete marking and the available technical data.
The exact item should be selected by its complete designation and technical parameters. Dimensions, design, material and operating conditions are important when matching a replacement.
For an accurate quotation, please provide the full marking, required quantity and any available documentation. We will compare the specification and verify a suitable delivery option.
