Bearing - 6307 C3 ZKL

51105 ZKL single-direction thrust ball bearing is a separable bearing for axial load in one direction. It consists of a shaft washer, housing washer and ball-and-cage assembly and is not designed to carry radial load.

35x72x17 mm

Single-row cylindrical roller bearing N 207 ZKL for high radial loads and accurate shaft guidance. The N design permits axial displacement of the shaft relative to the housing in both directions; when replacing, compare the complete designation and required internal clearance.

14x22x20 mm

Needle roller bearing without inner ring NK 14/20-XL INA for high radial loads in a compact space. The 14 mm dimension is the under-roller diameter, not a conventional bore; a suitably prepared shaft surface forms the inner raceway.

6014 2RSR FAG deep-groove ball bearing is a single-row bearing with RSR contact seals on both sides. It carries radial loads and moderate axial loads in both directions while protecting the factory grease against leakage, dust and moisture.

40x80x18 mm
Metal shields on both sides

Single-row deep-groove ball bearing 6208 2Z ROLLWAY for radial load and moderate axial loads in both directions. Non-contact metal shields retain grease with low friction and protect against ordinary dry contamination.

Four-point contact ball bearing Q 305 P63 DKF is a single-row angular contact bearing for axial loads in both directions. It provides bidirectional axial shaft location within a compact cross-section.

The P63 suffix combines P6 accuracy and C3 axial internal clearance. This version must match the application requirements and is not an automatic substitute for Normal accuracy or clearance.

65x120x24.75 mm

Single-row tapered roller bearing 30213 A P6X ZVL for combined radial load and axial load in one direction. The P6X precision version is intended for arrangements with higher dimensional and running-accuracy requirements; the complete A P6X designation must match the machine documentation.

Insert bearing YAR 206 2F SKF is designed for bearing units and is secured to the shaft by two set screws in the extended inner ring. This arrangement provides quick and reliable mounting.

A contact seal and flinger on both sides help protect the bearing from contaminants. The design is suitable for both constant and alternating directions of rotation.

20x52x22 mm
Greater radial internal clearance

Double-row angular-contact ball bearing 3304 C3 ZKL for rigid arrangements under combined loads. It carries radial load and axial loads in both directions; C3 clearance provides extra allowance where thermal expansion or tight fits reduce operating clearance.

40x48x20 mm

Full-complement drawn-cup needle roller bearing DL 4020 NADELLA with open ends and without an inner ring. It provides high radial load capacity within a very small radial section.
