Bearing - DL 4020 NADELLA

Not rated Rating details

€28,87 / pcs €23,86 excl. VAT

Delivery to: 10. 8. 2026 Delivery options

Quantity discount

1 - 4 pcs

€28,87 / pcs

5 - 9 pcs = discount 3 %

€28 / pcs

10 - 24 pcs = discount 6 %

€27,14 / pcs

25 - 49 pcs = discount 9 %

€26,27 / pcs

50 and more pcs = discount 12 %

€25,41 / pcs

You save €0

40x48x20 mm

Full-complement drawn-cup needle roller bearing DL 4020 NADELLA with open ends and without an inner ring. It provides high radial load capacity within a very small radial section.

Detailed information

What you get with us

We will help you choose the type

According to the designation and dimensions

Cash on delivery without extra charge

You only pay when you take over

Even hard-to-find components

Special and older types

Quick processing of requests

We will help you find a solution

Product detailed description

Full-complement drawn-cup needle roller bearing DL 4020 NADELLA

DL 4020 is an open needle roller bearing with a thin-walled drawn outer cup and a full complement of needle rollers. As it is supplied without an inner ring, a suitably prepared shaft surface serves directly as the inner raceway. Its radial section is only 4 mm, making it suitable for compact arrangements under high radial load.

Key features

Dimensions: 40 × 48 × 20 mm.
Type: full-complement drawn-cup needle roller bearing.
Design: open ends, without an inner ring and without a cage.
Load capability: high radial load capacity in a small radial envelope.
Brand: NADELLA.

The full complement of rollers increases radial load capacity but generally permits lower speeds than a caged design. The bearing is not intended to carry axial load; axial guidance must be provided by other machine elements.

When used as the raceway, the shaft must meet the hardness, accuracy, roundness and surface-finish requirements specified by NADELLA. Press the thin-walled cup into a dimensionally and geometrically correct housing bore using a suitable mounting mandrel; do not transmit mounting force through the rolling elements. Before installation, verify the complete DL 4020 designation and dimensions and provide the specified lubrication.
