Bearing 22317 KJB ZKL
Worldwide delivery
Best prices
Verified quality
Related products
Product detailed description
The ZKL 22317 spherical roller bearing is engineered to handle both radial and axial loads, making it suitable for a wide range of industrial applications.
Key Features:
-
Dimensions:
- Inner Diameter (d): 85 mm
- Outer Diameter (D): 180 mm
- Width (B): 60 mm
- Weight: 6.81 kg
-
Design:
- Double-row spherical roller bearing
- Symmetrical spherical rollers
- Steel cage for roller guidance
- Open design with a circumferential groove and three lubrication holes in the outer ring
-
Clearance:
- Standard radial internal clearance: Cn (normal internal play)
-
Lubrication:
- No lubrication groove or holes (W)
-
Precision:
- Standard precision
-
Temperature Range:
- Suitable for operating temperatures up to 120°C
-
Misalignment Capability:
- Can accommodate misalignment up to 2°
-
Load Ratings:
- Dynamic load rating (C₁₀): 530 kN
- Static load rating (C₀₁₀): 603 kN
-
Speed Ratings:
- Reference speed (n₀) with grease lubrication: 2,000 min⁻¹
- Reference speed (n₀) with oil lubrication: 2,600 min⁻¹
-
Mounting:
- Cylindrical bore (C)
This bearing is ideal for applications requiring high load capacity and the ability to accommodate misalignment, such as vibrating machinery and equipment.
For optimal performance, ensure proper lubrication and alignment during installation.
Be the first who will post an article to this item!
Add a rating
ZKL Bearings - Quality and Performance for Every Application
ZKL bearings are known for their high quality, reliability, and long service life. This renowned Czech manufacturer specializes in producing a wide range of bearings for various industrial sectors, including automotive, machinery, energy, and more. ZKL bearings are known for their excellent performance even under demanding conditions and are favored for their durability and long life.
Why Choose ZKL Bearings?
- Excellent Price/Performance Ratio: ZKL bearings offer great performance at a highly competitive price, making them an ideal choice for a wide range of applications.
- High Reliability: ZKL bearings are designed for long life and minimal maintenance, reducing repair and replacement costs over time.
- Variety of Products: ZKL offers a wide range of bearings, including ball, roller, and other types, which meet the specific requirements of various industrial applications.
Technical Specifications
ZKL bearings are designed to provide optimal performance in different conditions. They offer a wide selection of sizes and bearing types, including versions for high loads, high speeds, or extreme temperatures. Choose based on specifications such as diameter, width, material, and other technical parameters.
Contact Us
If you're looking for high-quality ZKL bearings for your applications, reach out to us. Our company provides not only top-notch products but also expert advice to help you select the right bearings for your specific needs. We are ready to ensure fast delivery and answer any questions you may have.
