Bearing NN 3019 KP/51 ZKL
Worldwide delivery
Best prices
Verified quality
Related products
Product detailed description
The NN 3019 KP/51 ZKL is a super-precision double-row cylindrical roller bearing that offers a unique balance between load-carrying capacity, rigidity, and speed. This bearing is particularly suitable for applications where high radial load capacity and precision are essential.
Key Features:
-
High Radial Load Capacity: Designed to handle substantial radial loads, making it suitable for demanding industrial applications.
-
High Rigidity and Running Accuracy: Ensures precise operation with minimal deflection, contributing to the overall performance and longevity of machinery.
-
Axial Displacement Accommodation: The design allows for axial displacement in both directions, providing flexibility in various mounting configurations.
-
Separable Design: Facilitates easy mounting and dismounting, especially when both rings require an interference fit.
-
Tapered Bore: Enables accurate adjustment of clearance or preload during mounting, ensuring optimal performance.
Technical Specifications:
-
Dimensions:
- Bore Diameter: 95 mm
- Outside Diameter: 145 mm
- Width: 37 mm
-
Load Ratings:
- Basic Dynamic Load Rating: 142 kN
- Basic Static Load Rating: 232 kN
-
Speed Capabilities:
- Attainable Speed for Grease Lubrication: 6,000 r/min
- Attainable Speed for Oil-Air Lubrication: 6,700 r/min
-
Design Features:
- Number of Rows: 2
- Bore Type: Tapered 1:12
- Cage Material: Non-metallic
- Number of Flanges, Outer Ring: 0
- Number of Flanges, Inner Ring: 3
- Radial Internal Clearance: C1
- Tolerance Class: Class SP
- Material: Bearing Steel
- Coating: Without
- Sealing: Without
- Lubricant: None
- Relubrication Feature: Without
-
Logistics:
- Product Net Weight: 1.98 kg
- eClass Code: 23-05-09-01
- UNSPSC Code: 31171505
This bearing is engineered to minimize noise, vibration, and heat generation, ensuring smooth and efficient operation in various industrial settings. Its separable design and tapered bore feature make it a versatile choice for applications requiring high precision and load capacity.
